| 加工定制：是 | 品牌：Futek | 型号：LRF350-300lb |
| 种类：湿度 | 制作工艺：集成 | 输出信号：模拟型 |
| 材料：金属 | 材料物理性质：导体 | 材料晶体结构：单晶 |
| 防护等级：IP68 | 线性度：25 | 迟滞：35 |
| 重复性：14 | 灵敏度：75 | 漂移：51 |
| 分辨率：78 |
美国Futek称重传感器LRF350-300lb
深圳市诗拓浦仪器仪表有限公司 陈先生 18026927816
美国Futek称重传感器LRF350-300lb
LSM200
The LSM200 Beam Load Cell offersa slim design with an easy side mounting feature making it ideal for OEMapplications. Utilized in both Tension and Compression, the Beam Load Cell hasa length of 1.75”, width of 0.38” and with a height of 0.36” it is well suitedfor tight spaces. The LSM200 is offered in 2024 Aluminum (10 lb) and it has a 2”Molex flexible 4 conductor type (1 mm pitch) cable.
Although the Beam Load Cell isspecifically built for low capacity applications, a built in overloadprotection provides the unit over 10 times the capacity that could take placeduring installation. As a part of FUTEK’s original product line, the Beam LoadCell can be modified or customized to meet your requirements and most capacitiesare in our inventory, making it available for 24 hour shipping. Similar to ourentire Load Cell product line this model is manufactured in the US and usesmetal foil strain gauge technology.
ProductHighlights:
Ideal for OEM Applications
In both Tension & Compression
Single Point Construction
Built in Overload Protection
Strain Gauge Based
1000 Ohm high resistance bridge
Weight: 3 oz
For those who are a looking for a completesystem solution, FUTEK can provide both signal conditioned displays or our VCalPortable System. FUTEK’s VCal Portable System brings an easy-to-use systemverification directly to the customer making it ideal for on-site verificationand calibration of your products. FUTEK LSM Series is also available with TEDS/ IEEE1451.4 option.
DIMENSION | VALUE |
Width (in) | 0.38 |
Height (in) | 0.36 |
Length (in) | 1.75 |
Weight (oz) | 3 |
NAME | MIN | TYP | MAX | UNIT |
CHANNEL 1 | ||||
Compensated Temperature (???) | 60 |
| 160 | F |
Excitation (???) | 1 |
| 18 | Vdc |
Hysteresis (???) | -0.2 |
| 0.2 | % of R.O. |
Input Resistance |
| 1000 |
| Ohms nom. |
Insulation Resistance | 500 |
|
| Mohms @ 50 Vdc |
Nonlinearity (???) | -0.2 |
| 0.2 | % of R.O. |
Nonrepeatability (???) | -0.1 |
| 0.1 | % of R.O. |
Operating Temperature (???) | -60 |
| 200 | F |
Output Resistance |
| 1000 |
| Ohms nom. |
Safe Overload (???) |
|
| 1000 | % of R.O. |
Temperature Shift Span (???) | -0.03 |
| 0.03 | % of Load/F |
Temperature Shift Zero (???) | -0.03 |
| 0.03 | % of R.O./F |
Zero Balance (???) | -5 |
| 5 | % of R.O. |
Zero Return | -0.1 |
| 0.1 | % of R.O. |
Capacity |
|
| 10 | lbs |
Rated Output (???) |
| 2.3 |
| mV/V nom. (???) |
Calibration Excitation |
| 10 |
| Vdc |
